Giriş
PCB Meclisi, PCB bileşenleri ve montajının yanı sıra basılı devre tasarımı, PCB imalatı ve nihai ürünün güçlü bir anlayışıyla ilgili bilgi gerektiren bir işlemdir. Devre kartı montajı, mükemmel ürünü ilk seferde sunmak için bulmacanın yalnızca bir parçasıdır.
San Francisco Circuits tüm devre kartı hizmetleri için tek çözümdür; bu nedenle tasarımdan montaja kadar PCB üretim süreciyle sıklıkla yerleşik kalırız. Güçlü bir şekilde kanıtlanmış devre montajı ve imalat ortakları ağı sayesinde, prototipiniz veya üretim PCB uygulamanız için en gelişmiş ve neredeyse sınırsız yetenekleri sağlayabiliriz. Satın alma süreciyle birlikte gelen sıkıntıdan kurtulun ve birden fazla bileşen satıcısı ile uğraşın. Uzmanlarımız size nihai ürününüz için en iyi parçaları bulacaktır.
PCB Montaj Hizmetleri:
Hızlı dönüş prototip montajı
Anahtar teslimi montaj
Kısmi anahtar-takımı
Konşimento montajı
RoHS uyumlu kurşunsuz montaj
RoHS olmayan montaj
Konformal kaplama
Nihai kutu kurma ve paketleme
PCB Montaj İşlemi
Delme ----- Pozlama ----- Kaplama ----- Etaching & Stripping ----- Delme ----- Elektriksel Test ----- SMT ----- Dalga Lehimleme --- --Aygıt Oluşturma ----- BİT ----- Fonksiyon Testi ----- Sıcaklık ve Nem Testi
Test Hizmetleri
X-Işını (2-D ve 3-D)
BGA X-Işını Muayene
AOI Testi (Otomatik Optik Muayene)
BİT Testi (Devre Dışı Test)
İşlevsel Testler (kurul ve sistem seviyesinde)
Uçan Prob
Yetenekler
Yüzeye Monte Teknolojisi / Parçaları (SMT Montajı)
Through-Hole Cihazı / Parçaları (THD)
Karışık Parçalar: SMT ve THD montajı
BGA / Mikro BGA / uBGA
QFN, POP ve kurşunsuz chip
2800 pin sayısı BGA
0201/1005 pasif bileşenler
0,3 / 0,4 Pitch
PoP Paketi
Flip-chip under-filled CCGA
BGA Aracı / Yığınlama
ve dahası…
Ürün ayrıntıları:
Ödeme & teslimat koşulları:
|
Vurgulamak: | pcb assembly services,pcba assembly |
---|
Quick Turn PCB Assembly Soldering Circuit MPPT Charge Controller In 48V
Quick Details
Description
Our production pcb assembly capabilities include machines placed SMT, THT, BGA and Micro BGAs, in addition to mixed technology PCB assembly. Keeping on the forefront of component requirements, we offer surface mount placement down to 12 mil pitch, with a component range of 0201 to 52 mm square QFPs and BGAs.
Parts & Component Sourcing
For Printed Circuit Board Assembly services, we accept components and parts in the following Two approaches.
1. Partial Turnkey,customer supply part components .
2. Full Turnkey, We purchase all the components from our Authority agent ,100% original guarantee.
Technical Capabilities
Type of assembly |
THD (Thru-hole device) / Conventional SMT (Surface-mount technology) SMT & THD mixed Double-sided SMT and/or THD assembly |
Order quantity |
1 to 100,000 |
Components |
Passives, smallest size 0201 Fine pitch to 08 Mils Leadless chip carriers/ BGA, VFBGA, FPGA & DFN Connectors and terminals |
Component packaging |
Reels Cut tape Tube Loose parts |
Board dimensions |
Smallest size: 6mm x 6mm Largest size: 600mm x 400mm |
Board shape |
Rectangular Round, Slots, Cutouts, Complex, Irregular |
Board type |
Rigid Flexible Rigid-flexible |
Solder Type |
Leaded and Lead-Free Water soluble solder paste Manual soldering for special parts, e.g. wires and temperature sensitive parts. |
Design file format |
Gerber RS-274X, 274D, Eagle and AutoCAD’s DXF, DWG BOM (Bill of Materials) Pick and Place file (XYRS) |
PCB Assembly Production Flow Chart
Testing Procedures
We perform multiple quality assurance procedures before shipping out any board. These include:
Visual inspection
X-ray Inspection
AOI (Automated Optical Inspector),
ICT (in-circuit test), and BGA Rework
Functional test (test modules need to be supplied) .
Quick turn lead times
If all the parts are available, normally the full turnkey pcb assembly job can be finished within 5 to 10 days in our factory. This means that the order can be delivered within three weeks once turnkey job start.
Service Guarantee
We make sure to serve each customer professionally, truthfully and friendly to the best of ourability. We will gladly re-work your project if your project isn’t 100% satisfactory.
Get a quick quote now
By sending in a bill of material, gerber files including assembly drawing and we will have a quotation back to you within hours. With Shenzhen hengda there is never a hidden cost and our prices are very competitive and reasonable.
